The structure of container is introduced. Bottom frame: it is the part that bears the load directly, and the lower part of the end frame and door frame is not connected, just combined by the lower side beam and bottom cross beam. When the container is handled by fork loader, the central part of the lower side beam of the container should be equipped with fork slot.
Steel containers generally use corrugated top plate, pressed from a whole sheet of steel, and then the corrugated top plate Han on the upper side beams, upper end beams and lintels. Aluminum containers generally use flat top plate, its top beam is usually made of aluminum stamping, and riveted, bolted or welded to the upper side beams. The box top plate is usually made of aluminum flat plate, which is bonded to the top beam to form the box top, which is then fixed with rivets on the upper side beams, upper end beams and lintels. Floor: now most of the floor of the container with wood, only a very small number of containers is a mixture of wood and steel plate, there are only steel floor. Side wall: the side wall is by the bottom of the box, the top of the box, the end frame and the door frame of the four components of the part of the enclosure, it plays a role in protecting the goods from theft and sheltering from the wind and rain. In the transportation process or loading and unloading, the side wall to withstand a certain cargo load, so the side wall also requires a certain degree of strength and rigidity.
Container in order to improve the strength and rigidity of the side wall with the end wall of the same corrugated steel. Door frame: door frame in addition to play the same role as the end frame, in order to be able to load and unload cargo and have an opening. In order to facilitate the loading and unloading of goods, the size of the opening should be as large as possible. It consists of lintel, threshold and two sets of corner structure, connected with the same method as the end frame. The lintel and threshold are equipped with a locking lever cam holder, and the box door is equipped with a door locking lever, which locks the door tightly by the locking lever cooperating with the cams at both ends. Box door and door locking device. The door is composed of door frame and door plate. The door plate has two kinds of flat plate and corrugated plate. Steel corrugated plate or flat plate are generally welded to the door frame. There are also metal cladding made of box door. Box door surrounded by neoprene or other synthetic materials made of gasket, used in the box when the door is closed to prevent water seepage inside the box.
